Specifications
|
Details
|
Unit
|
Substance |
Dimension |
Length
|
mm
|
2,710
|
Width
|
mm
|
1,530
|
Height
|
mm
|
1,805
|
Weight
|
Weight
|
Kg
|
855
|
Engine |
Model name
|
|
D4BB
|
Displacement
|
Cc
|
2,607
|
Maximum power
|
Ps/RPM
|
55/3,000
|
Capacity of engine oil
|
ℓ
|
6
|
Capacity of fuel tank
|
ℓ
|
40 |
FRP tank
|
Capacity
|
ℓ
|
1,000
|
Air blower
|
|
|
Single inlet multi bade type
|
Normal rotational speed
|
RPM
|
2,500
|
Elevation angle
|
°
|
225
|
Angle of traverse left and right
|
°
|
315
|
Air blower nozzle
|
Number of nozzles
|
EA
|
6
|
Diameter of nozzle
|
Mm
|
1.0~1.2
|
Sprayed capacity
|
ℓ/min
|
22.2
|
| Range |
M
|
30~45
|
Sprayed pump
|
Type
|
|
Type 3-plunger reciprocating
|
Normal rotational speed
|
RPM
|
750
|
| Normal pressure/maximum pressure
|
kg.f/cm²
|
30 / 60
|
Feed pump
|
Type
|
|
JET type
|
| Amount of water supplied
|
ℓ/min
|
133
|
| Sprayed capacity
|
m
|
Verticality 8~10
|
|
|
|
